L-934GT | Kingbright
LED, THT, Ø 3.2 mm, green, 568 nm, 18 to 60 mcd, 60°, L-934GT
Unit Price (€ / pc.)
0.2202 € *
Available: 978 pcs.
Total Price:
5.50 € *
Price list
Quantity
Price per unit*
25 pcs.
0.2202 €
125 pcs.
0.1952 €
500 pcs.
0.1749 €
2000 pcs.
0.1595 €
5000 pcs.
0.1452 €
*incl. VAT plus shipping costs
Subject to prior sale
Solid state lamp, L-934GT, Kingbright
The green source color device is made with gallium phosphide green light emitting diode.
Features
- Low power consumption
- General purpose leads
- Reliable and rugged
- Long life - solid state reliability
Technical specifications
| Filter | Property | Value |
|---|---|---|
| min. operating temperature | -40 °C | |
| max. operating temperature | 85 °C | |
| Assembly | THT | |
| On-State Voltage | 2.5 V | |
| Number of LEDs | 1 | |
| Light intensity min. | 0.018 cd | |
| Lens | green | |
| Colour of the LED | green | |
| Radiation angle | 60 ° | |
| diameter | 3.2 mm | |
| Forward Current | 20 mA | |
| Wavelength | 568 nm | |
| Light intensity typ. | 0.06 cd | |
| Length | 4.6 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85414100 |
| Country of origin | CN |
| Original Packaging | Bag with 1,000 pieces |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
