L-934GC | Kingbright
LED, THT, Ø 3 mm, green, 568 nm, 20 to 60 mcd, 50°, L-934GC
Unit Price (€ / pc.)
0.4641 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
2.32 € *
Price list
Quantity
Price per unit*
5 pcs.
0.4641 €
50 pcs.
0.3570 €
100 pcs.
0.2975 €
500 pcs.
0.2642 €
1000 pcs.
0.2404 €
*incl. VAT plus shipping costs
Subject to prior sale
Solid state lamp, L-934GC, Kingbright
The green source color device is made with gallium phosphide green light emitting diode.
Features
- Low power consumption
- General purpose leads
- Reliable and rugged
- Long life - solid state reliability
Technical specifications
| Colour of the LED | green | |
| Length | 5 mm | |
| Light intensity min. | 0.02 cd | |
| Number of LEDs | 1 | |
| On-State Voltage | 2.2 V | |
| Lens | clear | |
| Light intensity typ. | 0.06 cd | |
| Forward Current | 20 mA | |
| Wavelength | 568 nm | |
| Radiation angle | 50 ° | |
| diameter | 3 mm | |
| Assembly | THT |
Download
Logistics
| Original Packaging | Bag with 1,000 pieces |
| Customs tariff number | 85414100 |
| Country of origin | CN |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
