L-819EGW | Kingbright
LED, THT, Ø 10 mm, red/green, 568 nm, 0.05 cd, 50°, L-819EGW
Unit Price (€ / pc.)
0.2939 € *
Standard delivery time from the manufacturer is: 10 Weeks
Round LED lamp, L-819EGW, Kingbright
The high efficiency red source color device is made with gallium arsenide phosphide on gallium phosphide orange light emitting diode. The green source color device is made with gallium phosphide green light emitting diode.
Features
- Uniform light output
- Low power consumption
- Low power consumption
- Long life - solid state reliability
- RoHS compliant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Assembly | THT | |
| Number of LEDs | 2 | |
| Colour of the LED | red/green | |
| Light intensity typ. | 0.05 cd | |
| Radiation angle | 50 ° | |
| Lens | white | |
| On-State Voltage | 2.5 V | |
| Wavelength | 568 nm | |
| diameter | 10 mm | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 85 °C |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | CN |
| Original Packaging | Bag with 200 pieces |
| Customs tariff number | 85414100 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
