L-710A8CB/1GD | Kingbright
LED, THT, Ø 2.9 mm, green, 565 nm, 8 to 25 mcd, 50°, L-710A8CB/1GD
Unit Price (€ / pc.)
0.2321 € *
Standard delivery time from the manufacturer is: On Request
Right angled LED indicator, L-710A8CB/1GD, Kingbright
The green source color device is made with gallium phosphide green light emitting diode.
Features
- Pre-trimmed leads for pc mounting
- Black case enhances contrast ratio
- Wide viewing angle
- High reliability life measured in years
- RoHS compliant
Technical specifications
| On-State Voltage | 2.5 V | |
| Assembly | THT | |
| diameter | 2.9 mm | |
| Width | 4.6 mm | |
| Forward Current | 10 mA | |
| Length | 8.75 mm | |
| Wavelength | 565 nm | |
| Number of LEDs | 1 | |
| min. operating temperature | -40 °C | |
| Lens | green | |
| Colour of the LED | green | |
| max. operating temperature | 85 °C | |
| Radiation angle | 50 ° | |
| Light intensity min. | 0.008 cd | |
| Light intensity typ. | 0.025 cd |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85414100 |
| MSL | MSL 1 |
| Original Packaging | Bag with 500 pieces |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
