L-7104ZGC-G | Kingbright
LED, THT, Ø 3 mm, green, 8 to 14 cd, 34°, L-7104ZGC-G
Unit Price (€ / pc.)
0.357 € *
Standard delivery time from the manufacturer is: On Request
Solid state lamp, L-7104ZGC-G, Kingbright
The green source color device is made with InGaN light emitting diode. It is recommended to use a wrist band or anti-electrostatic glove when handling the LEDs.
Features
- Low power consumption
- General purpose leads
- Reliable and rugged
- Long life - solid state reliability
- RoHS compliant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Assembly | THT | |
| Number of LEDs | 1 | |
| Colour of the LED | green | |
| Light intensity min. | 8 cd | |
| Light intensity typ. | 14 cd | |
| Radiation angle | 34 ° | |
| Lens | clear | |
| On-State Voltage | 4 V | |
| Forward Current | 20 mA | |
| diameter | 3 mm | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 85 °C |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Bag with 500 pieces |
| Customs tariff number | 85414100 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
