L-115WEGW | Kingbright
LED, THT, Ø 3 mm, red/green, 568 nm, 10 mcd to 0.04 cd, 60°, L-115WEGW
Unit Price (€ / pc.)
0.3094 € *
Available: 836 pcs.
Total Price:
3.09 € *
Price list
Quantity
Price per unit*
10 pcs.
0.3094 €
50 pcs.
0.2559 €
100 pcs.
0.2118 €
500 pcs.
0.1630 €
1000 pcs.
0.1345 €
*incl. VAT plus shipping costs
Subject to prior sale
Bi-color indicator lamp, L-115WEGW, Kingbright
The high efficiency red source color device is made with gallium arsenide phosphide on gallium phosphide orange light emitting diode. The green source color device is made with gallium phosphide green light emitting diode.
Features
- Uniform light output
- Low power consumption
- 3 leads with one common lead
- Long life - solid state reliability
- RoHS compliant
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Assembly | THT | |
| Number of LEDs | 2 | |
| Colour of the LED | red/green | |
| Light intensity min. | 0.01 cd | |
| Light intensity typ. | 0.04 cd | |
| Radiation angle | 60 ° | |
| Lens | white | |
| On-State Voltage | 2.5 V | |
| Forward Current | 25 mA | |
| Wavelength | 568 nm | |
| Length | 5 mm | |
| diameter | 3 mm | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 85 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85414100 |
| Original Packaging | Bag with 500 pieces |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
