KP-1608SRD-PRV | Kingbright
LED, SMD, 0603, red, 660 nm, 40 to 70 mcd, 120°, KP-1608SRD-PRV
Discontinued
Unit Price (€ / pc.)
0.1714 € *
Available: 1,955 pcs.
Total Price:
0.17 € *
Price list
Quantity
Price per unit*
1 pcs.
0.1714 €
10 pcs.
0.1226 €
100 pcs.
0.1059 €
500 pcs.
0.1023 €
1000 pcs.
0.0964 €
2000 pcs.
0.0952 €
*incl. VAT plus shipping costs
Subject to prior sale
Red source color device, KP-1608SRD-PRV, Kingbright
The super bright red source color device is made with gallium aluminum arsenide red light emitting diode
Features
- Low power consumption
- Wide viewing angle
- Ideal for backlight and indicator
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Enclosure | 0603 | |
| Width | 0.8 mm | |
| Number of LEDs | 1 | |
| Light intensity typ. | 0.07 cd | |
| max. operating temperature | 85 °C | |
| Lens | red | |
| On-State Voltage | 2.5 V | |
| Wavelength | 660 nm | |
| Length | 1.6 mm | |
| Assembly | SMD | |
| Radiation angle | 120 ° | |
| Forward Current | 30 mA | |
| min. operating temperature | -40 °C | |
| Colour of the LED | red | |
| Light intensity min. | 0.04 cd |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Reel with 2,000 pieces |
| Customs tariff number | 85414100 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
