65.172 230VAC | Kendrion Kuhnke
3/2-way NC poppet valve, 0-5 bar, 230 V, 5 W, 65.172 230VAC
Unit Price (€ / pc.)
142.9190 € *
Standard delivery time from the manufacturer is: On Request
Total Price:
1,429.19 € *
Price list
Quantity
Price per unit*
10 pcs.
142.9190 €
25 pcs.
139.3371 €
50 pcs.
136.4811 €
*incl. VAT plus shipping costs
Subject to prior sale
Micro solenoid valves, type Kuhnke 65.
Directional 3/2-way poppet valve with standard socket; Pressure range: 8.0 bar. Pressurized media fitting: M 5. Electrical connection: 6.3 x 0.8 tab terminals. Degree of protection: IP 65. Design to VDE 0580/VDE 0110. Insulation class: E. Insulation group: C. Ambient temperatures: –10 to +50 °C.
3/2-way NC valves for 230 VAC, rated orifice 1.6, 5.0 bar pressure, type 65.172.
Rated coil power: approx. 5.0 VA, 50/60 Hz. Release power: 1.4 VA. Pickup time: 4.0 to 11 ms. Kv value: 0.9 l/min. Response current: approx. 1.5 x rated current.
Technical attributes (type, rated resistance, rated current): 65.172, 4950 ohm, 22 mA
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | 3/2-way NC poppet valve | |
| Nominal width | 1.6 mm | |
| Pressure range | 0-5 bar | |
| Rated voltage | 230 V | |
| Power | 5 W | |
| Connection | plug-in connection |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 84812090 |
| Country of origin | IT |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
