65.111 24VDC | Kendrion Kuhnke
3/2-way NC poppet valve, 0-8 bar, 24 V, 4.5 W, 65.111 24VDC
Unit Price (€ / pc.)
119.0476 € *
Standard delivery time from the manufacturer is: 8 Weeks
Total Price:
119.05 € *
Price list
Quantity
Price per unit*
1 pcs.
119.0476 €
5 pcs.
111.9076 €
15 pcs.
107.6117 €
50 pcs.
102.8398 €
*incl. VAT plus shipping costs
Subject to prior sale
Micro solenoid valves, type Kuhnke 65.
Directional 3/2-way poppet valve with standard socket; Pressure range: 8.0 bar. Pressurized media fitting: M 5. Electrical connection: 6.3 x 0.8 tab terminals. Degree of protection: IP 65. Design to VDE 0580/VDE 0110. Insulation class: E. Insulation group: C. Ambient temperatures: –10 to +50 °C.
3/2-way NC valves for 24 VDC, rated orifice NW 1.0, 8.0 bar pressure, type 65.111.
Rated coil power: approx. 4.5 W. Release power: 0.15 W. Pickup time: 10 to 15 ms. Kv value: 0.45 l/min.
Technical attributes (type, rated resistance, rated current): 65.111, 117 ohm, 205 mA
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | 3/2-way NC poppet valve | |
| Nominal width | 1 mm | |
| Pressure range | 0-8 bar | |
| Rated voltage | 24 V | |
| Power | 4.5 W | |
| Connection | plug-in connection |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 84812090 |
| Country of origin | IT |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
