46.007 | Kendrion Kuhnke
3/2-way NO poppet valve, 0-12 bar, 46.007
Pneumatic poppet valves, type Kuhnke 46.0.
With mounting strap. The servo control unit operates independent on the supply pressure and ensures that the valve can be actuated with different control pressures. Control pressure min./max; .: 1.5/8.0 bar. Pressure range: 0 to 12 bar. Return: spring. Rated orifice: NW 2 (2.0 mm). Function: 3/2-way. Housing: brass. Plunger: CrNi steel, corrosion resistant. Seals: Perbunan, oil-proof. Mounting position: any. Pressurized media fitting: M 5. Ambient temperatures: –10 to +70 °C. Medium: filtered, oiled, or filtered non-oiled compressed air, or other gaseous media with viscosity in accordance with ISO-VG 10.
Technical attributes (type, zero position, actuation): 46.007, NO, open in zero position, pressure on 10
| Filter | Property | Value |
|---|---|---|
| Pressure range | 0-12 bar | |
| Nominal width | 2 mm | |
| Connection | M5 connector | |
| Version | 3/2-way NO poppet valve |
| Property | Value |
|---|---|
| Customs tariff number | 84812090 |
| Country of origin | IT |
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
