SK050M0470B5S-1320 | Kemet

Electrolytic capacitor, 470 µF, 50 V (DC), ±20 %, radial, pitch 5 mm, Ø 13 mm, SK050M0470B5S-1320

Order No.: 11D5340
EAN: 4099879866899
MPN:
SK050M0470B5S-1320
ESK050M0470B5S-1320
Series: SK
SK050M0470B5S-1320 Kemet Electrolytic Capacitors Image 1
SK050M0470B5S-1320 Kemet Electrolytic Capacitors Image 2
Image may differ
Unit Price (€ / pc.)
0.1428 € *
Available in 4 Days: 7,202 pcs. - if ordered today
Total Price:
28.56 € *
*incl. VAT plus shipping costs
Subject to prior sale
200 pcs.
0.1428 €

Electrolytic capacitor in aluminum can, type Kemet Serie SK.

Wire connections on one side, for vertical PCB mounting, very high efficiency. Useful life 2000 h at +85 °C

Rated voltage 50 VDC, type SK050.

Technical specifications
Filter Property Value
Grid 5 mm
Design radial
max. operating temperature 85 °C
Version polar
Capacity 470 µF
diameter 13 mm
Ripple current 730 mA
min. operating temperature -40 °C
Tolerance ±20 %
Rated voltage (DC) 50 V
Length 20 mm
Logistics
Property Value
Country of origin CN
Original Packaging Bulk with 200 pieces
Customs tariff number 85322200
Compliance
Property Value
SVHC free Yes
Date of RoHS guidelines 3/31/15
RoHS conform Yes
