SH 100V/4,7UF | Kemet
Electrolytic capacitor, 4.7 µF, 100 V (DC), ±20 %, radial, pitch 2.5 mm, Ø 5 mm, SH 100V/4,7UF
Unit Price (€ / pc.)
0.1023 € *
Available: 1,985 pcs.
Available in 4 Days: 12,000 pcs. - if ordered today
Total Price:
0.10 € *
Price list
Quantity
Price per unit*
1 pcs.
0.1023 €
10 pcs.
0.0904 €
100 pcs.
0.0643 €
300 pcs.
0.0381 €
1000 pcs.
0.0262 €
*incl. VAT plus shipping costs
Subject to prior sale
Electrolytic capacitor in aluminum can, type Kemet Serie SH.
Wire connections on one side, for vertical PCB mounting.
Rated voltage 100 VDC.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 2.5 mm | |
| Ripple current | 37 mA | |
| min. operating temperature | -40 °C | |
| max. operating temperature | 105 °C | |
| Version | polar | |
| diameter | 5 mm | |
| Rated voltage (DC) | 100 V | |
| Tolerance | ±20 % | |
| Capacity | 4.7 µF | |
| Design | radial | |
| Length | 11 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322200 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
