160102509 | Kabeltronik
PVC-switching strand, extremely flexible, LifY, 0.25 mm², 128 x 0.05 mm, black, outer Ø 1.4 mm, 160102509
Unit Price (€ / mtr.)
0.5712 € *
Available: 356 mtr.
Available in 7 Days: 34,071 mtr. - if ordered today
Total Price:
0.57 € *
Price list
Quantity
Price per unit*
1 mtr.
0.5712 €
10 mtr.
0.5236 €
100 mtr.
0.4760 €
1000 mtr.
0.4165 €
2500 mtr.
0.3570 €
*incl. VAT plus shipping costs
Subject to prior sale
Stranded hook-up wires, ultra-flexible, type LifY.
Particularly suitable for applications demanding maximum flexibility
Cross-section 0.25 mm², outer diameter 1.4 mm,.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | switching strand | |
| Version | extremely flexible | |
| Cable cross-section | 0.25 mm² | |
| Cable structure | 128 x 0.05 mm | |
| Colour | black | |
| Core insulation material | PVC | |
| Outer diameter | 1.4 mm | |
| Halogen free | No | |
| Cable material | copper, bright | |
| Conductor category | CL.6 = finest stranded | |
| Temperature range (unmoved) | -30 °C to 70 °C | |
| Temperature range (active) | -5 °C to 70 °C | |
| Rated voltage | 900 V | |
| Test voltage | 2.5 kV |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Ring with 100 meters |
| Customs tariff number | 85444995 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
