340501000 | Kabeltronik
PVC control line LifYDY 5 x 0.10 mm², shielded, black, 340501000
Unit Price (€ / mtr.)
2.5823 € *
Available: 200 mtr.
Available in 7 Days: 14,335 mtr. - if ordered today
Total Price:
2.58 € *
Price list
Quantity
Price per unit*
1 mtr.
2.5823 €
10 mtr.
2.3205 €
50 mtr.
2.0706 €
100 mtr.
1.8921 €
500 mtr.
1.7255 €
*incl. VAT plus shipping costs
Subject to prior sale
Miniature control cable, 340501000, Kabeltronik
The 340501000 is a miniature control cable, preferably for applications in motion, without movement by compulsion and tensile load as well as miniature devices, alarm systems, light barriers, signalling systems, etc., where highest exibility and fail-safe characteristic with small outside diameter are necessary.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Temperature range (unmoved) | -20 °C to 70 °C | |
| Halogen free | No | |
| Number of cores | 5 | |
| Core insulation material | PVC | |
| Version | miniature control line | |
| Cable material | copper, bright | |
| Temperature range (active) | -5 °C to 70 °C | |
| Rated voltage | 300 V | |
| Test voltage | 900 V | |
| Material | PVC | |
| Shielding | shielded | |
| Colour | black | |
| Cable cross-section | 0.10 mm² |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
| Original Packaging | Reel with 100 meters |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
