PVC control line Sensocord 3 x 0.25 mm², unshielded, black, 245302509
Unit Price (€ / mtr.)
1.2614 € *
Available: 20 mtr.
Available in 7 Days: 15,382 mtr. - if ordered today
Total Price:
1.26 € *
Price list
Quantity
Price per unit*
1 mtr.
1.2614 €
10 mtr.
1.1067 €
100 mtr.
0.9877 €
500 mtr.
0.9163 €
1000 mtr.
0.7973 €
*incl. VAT plus shipping costs
Subject to prior sale
Sensor cables, non-shielded, type Kabeltronik Sensocord.
Cable for interconnecting sensors and actuators
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | PVC | |
| Cable material | copper, bright | |
| Version | control line | |
| Conductor category | CL.6 = finest stranded | |
| Number of cores | 3 | |
| Shielding | unshielded | |
| Core insulation material | PVC | |
| Test voltage | 2.5 kV | |
| Cable cross-section | 0.25 mm² | |
| Temperature range (unmoved) | -30 °C to 70 °C | |
| Temperature range (active) | -10 °C to 70 °C | |
| Outer diameter | 4.5 mm | |
| Colour | black | |
| Rated voltage | 900 V | |
| Halogen free | No |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Ring with 100 meters |
| Customs tariff number | 85444995 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
