PVC control line UL-LiYY 6 x 0.56 mm², AWG 20, unshielded, black, 095062009
Unit Price (€ / mtr.)
4.1055 € *
Available: 20 mtr.
Next delivery: 100 mtr. on 2025-12-11
Available in 7 Days: 9,628 mtr. - if ordered today
Total Price:
4.11 € *
Price list
Quantity
Price per unit*
1 mtr.
4.1055 €
10 mtr.
3.6652 €
100 mtr.
3.3320 €
500 mtr.
2.8798 €
1000 mtr.
2.5466 €
*incl. VAT plus shipping costs
Subject to prior sale
Control cables, non-shielded, to cULus, type UL-LiYY Style 2464/1061.
Cross-section AWG 20 (0.56 mm²).
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Number of cores | 6 | |
| Halogen free | No | |
| Core insulation material | PVC | |
| Standard number | UL | |
| Cable material | copper, tin-plated | |
| Core colour sequence | international color code | |
| Colour | black | |
| Product type | control line | |
| Outer diameter | 6.1 mm | |
| Cable cross-section | 0.56 mm² | |
| Test voltage | 1.5 kV | |
| Temperature range (active) | -15 °C to 80 °C | |
| Temperature range (unmoved) | -30 °C to 80 °C | |
| AWG cross-section | AWG 20 | |
| Rated voltage | 300 V | |
| Shielding | unshielded | |
| Material | PVC |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85444995 |
| Original Packaging | Ring with 100 meters |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
