JT-RD6006-C-B | joy-iT
Programmable laboratory power supply, 0 bis 60 V, outputs: 2 (6 A), 0 to 6 A, 360 W, 230 VAC, JT-RD6006-C-B
Order No.: 21K5960
EAN: 4250236827971
MPN:
JT-RD6006-C-B
Unit Price (€ / pc.)
218.9957 € *
Available: 2 pcs.
Laboratory power supply, JT-RD6006-C-B, joy-iT
The JT-RD6006-C-B is a reliable and powerful laboratory power supply unit. With an output voltage range of 0 - 60 V and a power of 0 - 360 W, you are able to master any type of project. The compact design and user-friendly operation make the JT-RD6006-C-B an excellent choice for any application. The 9 memory locations allow you to switch quickly and easily between different settings. The device can be operated via software using the USB interface. The device also has various protection and limiting functions such as constant voltage operation, constant current operation, overvoltage protection, overcurrent protection and replaceable fuses on the circuit board.
Technical specifications
| Range of Output Currence | 0 to 6 A | |
| Depth | 92 mm | |
| Output voltage DC | 0 to 60 V | |
| Output current | 6 A | |
| Width | 340 mm | |
| Height | 172 mm | |
| Power | 360 W | |
| Number of outputs | 2 | |
| Input voltage AC | 230 VAC |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85043200 |
| Original Packaging | Carton with 1 piece |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
