ECR1EPT221MFF350811 | Jianghai
Electrolytic capacitor, 220 µF, 25 V (DC), ±20 %, radial, pitch 3.5 mm, Ø 8 mm, ECR1EPT221MFF350811
Unit Price (€ / pc.)
0.3094 € *
Available: 964 pcs.
Total Price:
6.19 € *
Price list
Quantity
Price per unit*
20 pcs.
0.3094 €
100 pcs.
0.2154 €
500 pcs.
0.1630 €
2000 pcs.
0.1309 €
4000 pcs.
0.1154 €
*incl. VAT plus shipping costs
Subject to prior sale
Electrolytic capacitor in insulated aluminum can, type Jianghai CD 110 PT.
Radial wire connection of approx. 15/20 mm length
Rated voltage 25 VDC.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Ripple current | 349 mA | |
| Rated voltage (DC) | 25 V | |
| Connection | snap-in | |
| Tolerance | ±20 % | |
| Design | radial | |
| diameter | 8 mm | |
| ESR (Equivalent Series Resistance) | 1.013 Ω | |
| max. operating temperature | 85 °C | |
| min. operating temperature | -40 °C | |
| Version | polar | |
| Length | 11.5 mm | |
| Capacity | 220 µF | |
| Grid | 3.5 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85322200 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
