UMG 604E-PRO 230V (UL) | Janitza

Energy meter, Modbus RTU, Modbus Gateway, Modbus RTU over Ethernet, SNMP, Modbus TCP/IP, (L x W x H) 107.5 x 90 x 82 mm, UMG 604E-PRO 230V (UL)

Order No.: 30K4176
EAN: 4251861102181
MPN:
UMG 604E-PRO 230V (UL)
52.16.202
Series: UMG
UMG 604E-PRO 230V (UL) Janitza Energy Measurement
Image may differ
Unit Price (€ / pc.)
1,010.31 € *
Available: 1 pcs.
Available in 5 Days: 25 pcs. - if ordered today
Total Price:
1,010.31 € *
*incl. VAT plus shipping costs
Subject to prior sale
1 pcs.
1,010.31 €

High performance power quality analyzer, 5216202, Janitza

Power Analyser, (UL), Supply voltage: 95...240V (45-65Hz) 135...340V DC , Measurement category: 300V CATIII , 4 voltage measurement inputs, 4 current measurement inputs , Measurement range: L - N: 10 -300V L - L: 17 - 520V 45 - 65Hz , Current transformers:.../1,.../5A , 2 digital inputs, 2 digital outputs , 1 temperature measurement input , Additional memory: 128MB Flash , Interfaces: RS232, RS485 , Interface: Ethernet 10/100 BaseTX, Incl.Web-Server as well as the following APP`s , APP Measured Value Monitor: Graphical display of online & historical measured values , APP IEC 61000-2-4 Watchdog Light PRO: Monitoring of voltage quality limits according to IEC 61000-2-4, APP Push Service PRO: Transfer of measured data to cloud based software solutions

Technical specifications
Filter Property Value
Length 107.5 mm
Height 82 mm
Version Modbus RTU, Modbus Gateway, Modbus RTU over Ethernet, SNMP, Modbus TCP/IP
Product type energy meter
Weight 350 g
Width 90 mm
Logistics
Property Value
Country of origin DE
Customs tariff number 90303200
Compliance
Property Value
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
