VMS-R020-1.0 | Isabellenhütte
Resistor, metal foil, SMD 2512 (6330), 20 mΩ, 3 W, ±1 %, VMS-R020-1.0
Unit Price (€ / pc.)
2.6537 € *
Available: 64 pcs.
Total Price:
2.65 € *
Price list
Quantity
Price per unit*
1 pcs.
2.6537 €
25 pcs.
2.2610 €
100 pcs.
2.0944 €
250 pcs.
1.9873 €
1000 pcs.
1.8207 €
*incl. VAT plus shipping costs
Subject to prior sale
SMD precision resistor, size 2512, 3.0 W, tolerance 1.0 %, series ISA-PLAN, type Isabellenhütte VMS.
Suitable for use as measuring resistance in switching mode power supplies, power modules, frequency converters, controllers and power hybrids
Technical specifications
| Filter | Property | Value |
|---|---|---|
| min. operating temperature | -65 °C | |
| max. operating temperature | 170 °C | |
| Height | 0.4 mm | |
| Tolerance | ±1 % | |
| Width | 3 mm | |
| ohmic resistance | 20 mΩ | |
| Power | 3 W | |
| Length | 6.35 mm | |
| Temperature coefficient | ±20 ppm/K | |
| Design | SMD 2512 (6330) | |
| Technology | metal foil |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Reel with 9,000 pieces |
| Customs tariff number | 85332100 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
