EPM9560RC240-15 | INTEL
CPLD MAX® 9000 Family 12K Gates 117.6MHz 5V
Complex programmable logic device, EPM9560RC240-15, Intel
The EPM9560RC240-15 is an in-system-programmable, high-density, high performance EPLDs it is based on third-generation architecture, it is fabricated on an advanced CMOS technology.
Features
- High-density erasable programmable logic device
- Programmable security bit for protection of proprietary designs
- Dual-output macrocell for independent use of combinatorial and registered logic
- Programmable power-saving mode for a reduction of over 50% in each macrocell
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Enclosure | BFQFP-240 | |
| Assembly | SMD | |
| Number of I/Os | 191 | |
| Propagation Delay | 15 s | |
| Voltage | 4.75-5.25 V | |
| Number of logical elements | 35 | |
| Number of macro cells | 560 | |
| min. operating temperature | 0 °C | |
| max. operating temperature | 70 °C |
Download
Logistics
| Property | Value |
|---|---|
| Original Packaging | Tray with 24 pieces |
| MSL | MSL 3 |
| Customs tariff number | 85423990 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 6/8/11 |
| SVHC free | Yes |
| RoHS conform | Yes |
