KX5001 | IFM electronic
Capacitive sensor, NAMUR, flush mounting M34, not flush, 1 Form B (N/C), KX5001
Order No.: 82P6452
EAN: 4021179149136
MPN:
KX5001
Unit Price (€ / pc.)
300.7249 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
300.72 € *
Price list
Quantity
Price per unit*
1 pcs.
300.7249 €
3 pcs.
292.8471 €
*incl. VAT plus shipping costs
Subject to prior sale
Capacitive sensor, KX5001, IFM electronic
Features
- For applications in hazardous areas
- Easy setting of the sensing range via potentiometer
- Clearly visible indication of the switching status by LED
- For connection to intrinsically safe circuits
- High mechanical stability thanks to robust metal housing
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Length | 92 mm | |
| Version | NAMUR | |
| Connection | cable, PVC 3x0.5 mm², 2 m | |
| Degree of protection (IP) | IP65 | |
| Product type | capacitive sensor | |
| Assembly | flush mounting M34, not flush | |
| Latching switching function | 1 Form B (N/C) | |
| Detecting distance | 15 mm |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85365019 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
