KG5040 | IFM electronic
Capacitive sensor, PNP/NPN, flush mounting M18, not flush, 1 Form A (N/O) + 1 Form B (N/C), 55 V (DC), 200 mA, KG5040
Order No.: 82P6343
EAN: 4021179146203
MPN:
KG5040
Unit Price (€ / pc.)
214.2000 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
214.20 € *
Price list
Quantity
Price per unit*
1 pcs.
214.2000 €
3 pcs.
208.5951 €
*incl. VAT plus shipping costs
Subject to prior sale
Capacitive sensor, KG5040, IFM electronic
Features
- Easy setting of the sensing range via potentiometer
- Output function normally open / normally closed programmable
- Clearly visible indication of the switching status
- Two-wire technology
- With terminal chamber that can be rotated by 90°
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Latching switching function | 1 Form A (N/O) + 1 Form B (N/C) | |
| Detecting distance | 2.5-8 mm | |
| Degree of protection (IP) | IP65 | |
| Version | PNP/NPN | |
| Connection | connection terminal 2.5 mm²/cable gland M16 | |
| Assembly | flush mounting M18, not flush | |
| switching current | 200 mA | |
| Switching Voltage (DC) | 55 V | |
| Length | 110 mm | |
| Product type | capacitive sensor |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365019 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
