KB0029 | IFM electronic
Capacitive sensor, PBT, flush mounting, not flush, 1 Form B (N/C), 250 V (DC), 200 mA, KB0029
Order No.: 82P6324
EAN: 4021179143615
MPN:
KB0029
Unit Price (€ / pc.)
277.4604 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
277.46 € *
Price list
Quantity
Price per unit*
1 pcs.
277.4604 €
3 pcs.
270.1895 €
*incl. VAT plus shipping costs
Subject to prior sale
Capacitive sensor, KB0029, IFM electronic
Features
- With combined AC/DC output stage
- Two-wire technology
- Smooth plastic housing to protect against deposits
- Easy setting of the sensing range via potentiometer
- High noise immunity
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Latching switching function | 1 Form B (N/C) | |
| Detecting distance | 3-20 mm | |
| Degree of protection (IP) | IP65 | |
| Version | PBT | |
| Connection | cable, PVC 2x0.5 mm², 2 m | |
| Assembly | flush mounting, not flush | |
| switching current | 200 mA | |
| Switching Voltage (AC) | 250 V | |
| diameter | 34 mm | |
| Switching Voltage (DC) | 250 V | |
| Length | 81 mm | |
| Product type | capacitive sensor |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365080 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
