KB0025 | IFM electronic
Capacitive sensor, PBT, flush mounting, not flush, 1 Form A (N/O), 250 V (DC), 200 mA, KB0025
Unit Price (€ / pc.)
272.5814 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
272.58 € *
Price list
Quantity
Price per unit*
1 pcs.
272.5814 €
3 pcs.
265.4414 €
*incl. VAT plus shipping costs
Subject to prior sale
Capacitive sensor, KB0025, IFM electronic
Features
- With combined AC/DC output stage
- Two-wire technology
- Smooth plastic housing to protect against deposits
- Easy setting of the sensing range via potentiometer
- High noise immunity
Technical specifications
| Filter | Property | Value |
|---|---|---|
| diameter | 34 mm | |
| Switching Voltage (DC) | 250 V | |
| Connection | cable, PVC 2x0.5 mm², 2 m | |
| Latching switching function | 1 Form A (N/O) | |
| switching current | 200 mA | |
| Length | 81 mm | |
| Product type | capacitive sensor | |
| Detecting distance | 3-20 mm | |
| Assembly | flush mounting, not flush | |
| Degree of protection (IP) | IP65 | |
| Switching Voltage (AC) | 250 V | |
| Version | PBT |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
