IM0011 | IFM electronic
Inductive sensor, PPE, flush mounting, flush, 1 Form A (N/O) + 1 Form B (N/C), 250 V (DC), 100 mA, IM0011
Unit Price (€ / pc.)
158.9959 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
159.00 € *
Price list
Quantity
Price per unit*
1 pcs.
158.9959 €
3 pcs.
154.5929 €
5 pcs.
150.4398 €
*incl. VAT plus shipping costs
Subject to prior sale
Inductive sensor, IM0011, IFM electronic
Features
- Long sensing range for use in conveying
- With combined AC/DC output and two-wire technology
- Output function normally open / normally closed programmable
- Robust housing for use in harsh industrial environments
- Large operating voltage range
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Switching Voltage (AC) | 250 V | |
| Connection | connection terminal 2.5 mm²/cable gland M20 | |
| Detecting distance | 15 mm | |
| Latching switching function | 1 Form A (N/O) + 1 Form B (N/C) | |
| Switching Voltage (DC) | 250 V | |
| Degree of protection (IP) | IP65 | |
| Length | 120 mm | |
| Assembly | flush mounting, flush | |
| switching current | 100 mA | |
| Version | PPE | |
| Product type | inductive sensor |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | RO |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
