Inductive sensor, ID0013, IFM
The ID0013 is a inductive sensor with combined AC/DC output and two-wire technology. This prduct has a very long sensing range and large active sensor face.
Features
- Easy setting of the sensing range via potentiometer
- Output function normally open / normally closed programmable
- Robust housing for use in harsh industrial environments
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Switching Voltage (DC) | 250 V | |
| Connection | connection terminal 2.5 mm²/cable gland M20 | |
| Latching switching function | 1 Form A (N/O) + 1 Form B (N/C) | |
| switching current | 100 mA | |
| Length | 105 mm | |
| Product type | inductive sensor | |
| Detecting distance | 60 mm | |
| Assembly | flush mounting, not flush | |
| Degree of protection (IP) | IP65 | |
| Switching Voltage (AC) | 250 V | |
| Version | PPE modified |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85365080 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
