I85009 | IFM electronic
Inductive hose sensor, PNP, 1 Form A (N/O), 35 V (DC), 200 mA, I85009
Order No.: 82P5012
EAN: 4021179279222
MPN:
I85009
Unit Price (€ / pc.)
183.4980 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
183.50 € *
Price list
Quantity
Price per unit*
1 pcs.
183.4980 €
3 pcs.
178.6904 €
*incl. VAT plus shipping costs
Subject to prior sale
Tube sensor, I85009, IFM electronic
Features
- Dynamic principle of operation
- Reliable detection of objects with very small diameters
- Very short response time
- Output function normally open / normally closed programmable
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Latching switching function | 1 Form A (N/O) | |
| Detecting distance | < 14 mm | |
| Degree of protection (IP) | IP67 | |
| Version | PNP | |
| Connection | cable, PUR, 0.09 m/M12 connector | |
| switching current | 200 mA | |
| Switching Voltage (DC) | 35 V | |
| Length | 70 mm | |
| Product type | inductive hose sensor |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365019 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
