PX9111 | IFM electronic
Pressure transmitter, 0-3000 psi/0-20700 kPa, 16-32 VDC, PX9111
Unit Price (€ / pc.)
394.7230 € *
Standard delivery time from the manufacturer is: 1 Week
Total Price:
394.72 € *
Price list
Quantity
Price per unit*
1 pcs.
394.7230 €
3 pcs.
384.7746 €
*incl. VAT plus shipping costs
Subject to prior sale
Electronic pressure sensor, PX9111, IFM electronic
Features
- Reliable detection of system pressure in industrial and mobile applications
- Precise analogue output
- With long-term stability thanks to high overload protection
- Lifespan of more than 100 million pressure cycles
- High shock and vibration resistance
Technical specifications
| Filter | Property | Value |
|---|---|---|
| diameter | 30 mm | |
| max. operating temperature | 80 °C | |
| Length | 79.5 mm | |
| min. operating temperature | -25 °C | |
| Assembly | 1/4" NPT external thread, M5 internal thread | |
| Voltage | 16-32 VDC | |
| measurement range | 0-3000 psi/0-20700 kPa | |
| Connection | M12-connector | |
| Product type | pressure transmitter | |
| Version | relative pressure, analog signal | |
| Enclosure | cylindrical |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 90262020 |
| Country of origin | RO |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
