SD0550 | IFM electronic
Compressed air counter, with display, IO-Link, PNP, 2 bar, stainless steel/PTFE/PBT-GF20/PC/NBR/brass/aluminum/FKM, SD0550
Order No.: 82P8260
EAN: 4021179326001
MPN:
SD0550
Unit Price (€ / pc.)
1,187.0726 € *
Standard delivery time from the manufacturer is: 1 Week
Compressed air meter, SD0550, IFM electronic
Features
- Precise measurement of flow, consumption and medium temperature
- High accuracy, repeatability and measurement dynamics
- For detecting compressed air in industrial use
- With switching output, analogue output and pulse output
- Clearly visible 4-digit LED display
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Latching switching function | Form A (N/O)/Form B (N/C) | |
| Medium | air | |
| Shell Material | stainless steel/PTFE/PBT-GF20/PC/NBR/brass/aluminum/FKM | |
| Version | with display, IO-Link, PNP | |
| Connection | M12-connector | |
| Assembly | threaded connection G 1/4, female thread DN8 | |
| measurement range | 1-250 l/min, 0.3-82.9 m/s, 0.04-15 m³/h | |
| Pressure | 2 bar | |
| Product type | compressed air counter |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 90268020 |
| Country of origin | DE |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
