SA6010 | IFM electronic
Flow sensor, with display, IO-Link, PNP/NPN, 100 bar, Ø 34 mm, stainless steel, SA6010
Order No.: 82P8179
EAN: 4021179297769
MPN:
SA6010
Unit Price (€ / pc.)
512.4854 € *
Available: 0 pcs.
Leadtime: 1 Week **
Flow sensor, SA6010, IFM electronic
Features
- Measurement of flow and temperature at the same time
- Optimised for water, oils and air
- Red/green display for clear identification of the acceptable range
- With switching output, analogue signal and IO-Link
- The process connection can be rotated for optimum alignment
Technical specifications
| Degree of protection (IP) | IP65/IP67 | |
| Assembly | 1/2" NPT external thread | |
| Medium | water/oils/glycol solutions/air | |
| diameter | 34 mm | |
| Product type | flow sensor | |
| Version | with display, IO-Link, PNP/NPN | |
| Shell Material | stainless steel | |
| Connection | M12-connector | |
| measurement range | -4-194 °F, 0-9.85 ft/s, 0-328 ft/s, rod length 26.6 mm | |
| Latching switching function | Form A (N/O)/Form B (N/C) | |
| Pressure | 100 bar |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 90261021 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
