YW1B-M1E10R | IDEC
Pushbutton, unlit, groping, 1 Form A (N/O), waistband round, red, mounting Ø 22 mm, YW1B-M1E10R
Unit Price (€ / pc.)
8.0444 € *
Available: 8 pcs.
Total Price:
8.04 € *
Price list
Quantity
Price per unit*
1 pcs.
8.0444 €
10 pcs.
7.6636 €
50 pcs.
7.3066 €
100 pcs.
6.9377 €
*incl. VAT plus shipping costs
Subject to prior sale
Pushbutton, YW1B-M1E10R, IDEC
Pushbutton with plastic bezel. Can be unlatched by either pulling or turning the operator with Push-to-lock, Pull/Turn-to-release feature.
Features
- Safety lock mechanism
- Direct opening action
- Safe pushbutton design
- Self-cleaning contacts
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Collar shape of the front frame | round | |
| Protection class | IP65 | |
| Latching switching function | 1 Form A (N/O) | |
| Contact function | groping | |
| can be illuminated | No | |
| Installation depth | 45.8 mm | |
| Installation diameter | 22 mm | |
| Actuator colour | red | |
| Connection | screw connection | |
| Product type | pushbutton | |
| Contact material | silver | |
| Installation height | 11 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85365011 |
| Country of origin | CN |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
