975163104 | Hirschmann Test & Measurement

Name: Measuring lead with (4 mm plug, spring-loaded, straight) to (2 mm plug, spring-loaded, straight), 1 m, green, PVC, 1.0 mm², CAT II, 975163104
Brand: Hirschmann Test & Measurement
SKU: 86F3385
Availability: InStock

Measuring lead with (4 mm plug, spring-loaded, straight) to (2 mm plug, spring-loaded, straight), 1 m, green, PVC, 1.0 mm², CAT II, 975163104

Order No.: 86F3385

EAN: 4099891949396

MPN:

975163104

MAL S WS 2-4 100/1 AU GN

Series: MAL S WS 2-4

Unit Price (€ / pc.)

10.1864 € *

Total Price:

10.19 € *

*incl. VAT plus shipping costs

Subject to prior sale

Description

Measuring lead, MAL S WS 2-4 100/1 AU GN, Hirschmann Test & Measurement

The MAL S WS 2-4 100/1 AU GN is a safety measuring lead according to IEC 61010, one end with 2mm safety plug and other end with 4mm safety plug, as well as 2 mm and 4 mm socket for onward connection capability. Gold-plated / nickel-plated copper-beryllium contact spring. Highly flexible, double insulated stranded lead, with good firm grip sleeves. Built in color indicator to detect damage to the cable insulation

Technical specifications

Filter	Property	Value
	Connection (1)	4 mm plug, spring-loaded, straight
	Connection (2)	2 mm plug, spring-loaded, straight
	Cable length	1 m
	Cable cross-section	1.0 mm²
	Colour	green
	Material	PVC
	contact surface	gold-plated
	Rated category	CAT II
	Rated Voltage	1000 V
	Rated current	10 A
	Touch safe	Yes
	Stackable	Yes
