931376100 | Hirschmann Test & Measurement
Miniature test probe, solder connection, 30 V, black, 931376100
Unit Price (€ / pc.)
2.4752 € *
Available: 20 pcs.
Available in 6 Days: 380 pcs. - if ordered today
Total Price:
2.48 € *
Price list
Quantity
Price per unit*
1 pcs.
2.4752 €
20 pcs.
2.2253 €
60 pcs.
2.1063 €
100 pcs.
1.9754 €
500 pcs.
1.8564 €
*incl. VAT plus shipping costs
Subject to prior sale
Miniature test probes, type Hirschmann T & M PRUEF 1.
With step-on proof removable grip. For sampling the most intricate measuring points. The stainless steel tip easily penetrates insulation and oxide layers; Solder connection: up to 0.5 mm². Contact material: nickel-plated stainless steel. Rated voltage: 60 VDC. Contact resistance: 50 mohm. Operating temperatures: –25 to +60 °C.
Technical attributes (type, color): PRUEF 1, black
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Product type | miniature test probe | |
| Connection | solder connection | |
| Rated Voltage | 30 VAC/60 VDC | |
| Rated voltage | 30 V | |
| Rated category | CAT O | |
| Colour | black | |
| Material Insulation | PVC | |
| Contact material | brass, nickel-plated |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | DE |
| Customs tariff number | 85369095 |
Compliance
| Property | Value |
|---|---|
| Sustainable | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
