930518500 | Hirschmann Automation and Control
Panel socket, 7 pole, THT, angled, 930518500
DIN audio connector, plastic, type Hirschmann MA..
to EN 60130-09 and DIN 45329, solder terminals for conductors to max. 0.34 mm². Contacts: tinned brass.Contact block: PA 66 to UL 94 V-2. Rated voltage: 34 V AC/DC. Rated current: 4.0 A. Degree of protection (IEC 60529): IP 30. Operating temperatures: - 20 to +60 °C.
DIN audio panel jacks, type MAB.
Panel jack for PCB mounting. Insertion in parallel to the panel level. With additional screw fastening (DIN 40081), without screw lock; Contact block and housing material: PBT to UL 94 V-0.
Type: MAB 7 SH - L SN, black
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | DIN panel socket | |
| Cable cross-section | 0.34 mm² | |
| Pin number | 7 pole | |
| Orientation | angled | |
| Contact connection | THT | |
| Assembly | PCB mounting | |
| Additional parts | equipped | |
| Shell Material | plastic |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85366930 |
| Country of origin | CZ |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
