0 634 132 | Hengstler
Panel-mount pulse counter, 0 634 132
Order No.: 30K4130
EAN: 4099891455040
MPN:
0 634 132
Unit Price (€ / pc.)
40.0554 € *
Standard delivery time from the manufacturer is: 3 Weeks
Panel pulse counters, type Hengstler 634.
For PCB mounting. With high level of EMI protection Without reset function. Machine-solderable, wash-proof; Mounting position: horizontal scrolling display. Power consumption: 50 to 440 mW. Voltage tolerance: ±10 %. Count rate: max. 10 pps. Pulse duration: min. 50 ms. Duty cycle: 100 %. Operating temperatures: –10 to +50 °C. Number of digits: 6. Digit height: 4.0 mm. Useful life: 10 million pulses. Magnetic influence: at 100 kA/m (PTB), insensitive to disturbance.
Horizontal, with display at the top, type 0634.1.
Degree of protection: housing IP 65, connections IP 00.
Type: 0 634 132, 5.0 VDC, 335 ohm
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Degree of protection (IP) | IP65 | |
| Assembly | built-in mounting | |
| Voltage | 230 VAC | |
| Counting frequency | 10 Hz | |
| Pulse duration | 50 ms |
Download
Logistics
| Property | Value |
|---|---|
| Country of origin | SK |
| Customs tariff number | 90291000 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 7/1/06 |
| RoHS conform | not_relevant |
