45157 | HELUKABEL
Flat ribbon cable in round form, 26 pole, pitch 1.27 mm, 0.09 mm², AWG 28, PVC, gray, 45157
Unit Price (€ / mtr.)
26.4537 € *
Available in 5 Days: 1,100 mtr. - if ordered today
Ribbon cable, 45157, HELUKABEL
The 45157 is a flat ribbon cable, due to its roundshape offers considerable advantages compared with other flat ribbon cables during the installation and assembly. This roundshaped cable bids enormous profits by using the quick and economical possibilities under continuance with the efficient connection in IDC-technique. All conductors can be contacted at one working procedure without stripping the insulation. The accurate to size pitch-image of the ribbon cable is obtained due to an adapted backshaping before the plug installation.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Width | 33.02 mm | |
| Colour | gray | |
| Outer diameter | 9 mm | |
| AWG cross-section | AWG 28 | |
| Number of cores | 26 | |
| Core insulation material | PVC | |
| Temperature range (unmoved) | -20 °C to 80 °C | |
| Rated voltage | 300 V | |
| Halogen free | No | |
| Cable material | copper, tin-plated | |
| Version | flat ribbon cable in round form | |
| Shielding | shielded | |
| Test voltage | 2 kV | |
| Cable cross-section | 0.09 mm² | |
| Grid | 1.27 mm |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
