45156 | HELUKABEL
Flat ribbon cable in round form, 25 pole, pitch 1.27 mm, 0.09 mm², AWG 28, PVC, gray, 45156
Unit Price (€ / mtr.)
40.0197 € *
Available in 5 Days: 700 mtr. - if ordered today
Ribbon cable, 45156, HELUKABEL
The 45156 is a flat ribbon cable, due to its roundshape offers considerable advantages compared with other flat ribbon cables during the installation and assembly. This roundshaped cable bids enormous profits by using the quick and economical possibilities under continuance with the efficient connection in IDC-technique. All conductors can be contacted at one working procedure without stripping the insulation. The accurate to size pitch-image of the ribbon cable is obtained due to an adapted backshaping before the plug installation.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Core insulation material | PVC | |
| AWG cross-section | AWG 28 | |
| Shielding | shielded | |
| Cable material | copper, tin-plated | |
| Colour | gray | |
| Cable cross-section | 0.09 mm² | |
| Grid | 1.27 mm | |
| Halogen free | No | |
| Rated voltage | 300 V | |
| Test voltage | 2 kV | |
| Outer diameter | 9 mm | |
| Number of cores | 25 | |
| Width | 31.75 mm | |
| Temperature range (unmoved) | -20 °C to 80 °C | |
| Version | flat ribbon cable in round form |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
