45154 | HELUKABEL
Flat ribbon cable in round form, 20 pole, pitch 1.27 mm, 0.09 mm², AWG 28, PVC, gray, 45154
Unit Price (€ / mtr.)
24.5140 € *
Standard delivery time from the manufacturer is: 6 Weeks
Ribbon cable, 45154, HELUKABEL
The 45154 is a flat ribbon cable, due to its roundshape offers considerable advantages compared with other flat ribbon cables during the installation and assembly. This roundshaped cable bids enormous profits by using the quick and economical possibilities under continuance with the efficient connection in IDC-technique. All conductors can be contacted at one working procedure without stripping the insulation. The accurate to size pitch-image of the ribbon cable is obtained due to an adapted backshaping before the plug installation.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Grid | 1.27 mm | |
| Test voltage | 2 kV | |
| Width | 25.4 mm | |
| Outer diameter | 7.8 mm | |
| Shielding | shielded | |
| Cable material | copper, tin-plated | |
| Number of cores | 20 | |
| Core insulation material | PVC | |
| Temperature range (unmoved) | -20 °C to 80 °C | |
| Version | flat ribbon cable in round form | |
| Halogen free | No | |
| Rated voltage | 300 V | |
| Cable cross-section | 0.09 mm² | |
| AWG cross-section | AWG 28 | |
| Colour | gray |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
