45150 | HELUKABEL
Flat ribbon cable in round form, 9 pole, pitch 1.27 mm, 0.09 mm², AWG 28, PVC, gray, 45150
Unit Price (€ / mtr.)
17.1479 € *
Available in 5 Days: 200 mtr. - if ordered today
Ribbon cable, 45150, HELUKABEL
The 45150 is a flat ribbon cable, due to its roundshape offers considerable advantages compared with other flat ribbon cables during the installation and assembly. This roundshaped cable bids enormous profits by using the quick and economical possibilities under continuance with the efficient connection in IDC-technique. All conductors can be contacted at one working procedure without stripping the insulation. The accurate to size pitch-image of the ribbon cable is obtained due to an adapted backshaping before the plug installation.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Version | flat ribbon cable in round form | |
| Number of cores | 9 | |
| Grid | 1.27 mm | |
| Cable cross-section | 0.09 mm² | |
| AWG cross-section | AWG 28 | |
| Cable material | copper, tin-plated | |
| Core insulation material | PVC | |
| Colour | gray | |
| Outer diameter | 6.3 mm | |
| Width | 11.43 mm | |
| Halogen free | No | |
| Shielding | shielded | |
| Rated voltage | 300 V | |
| Test voltage | 2 kV | |
| Temperature range (unmoved) | -20 °C to 80 °C |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
