90408 | HELUKABEL

Corrugated hose, inside Ø 66.5 mm, outside Ø 79.2 mm, BR 200 mm, PA, gray, 90408

Order No.: 93F7361
EAN: 4060892380143
MPN:
90408
Series: JUMBO PA6
90408 HELUKABEL Protective Tubes
Image may differ
Unit Price (€ / mtr.)
19.2423 € *
Available in 5 Days: 30 mtr. - if ordered today
Total Price:
192.42 € *
*incl. VAT plus shipping costs
Subject to prior sale
10 mtr.
19.2423 €

Corrugated tube, 90408, HELUKABEL

The 90408 is a cable protection tube for medium to heavy-duty applications. This product is resistant to: fuels, mineral oils, greases, weak bases, weak acids.

Features

  • Halogen-free
  • Cadmium-free

Applications

  • Machine and plant construction
  • Robotics
  • Automation technology
  • Vehicle construction and shipbuilding
  • Railway technology
  • Installation technology
  • Control cabinet construction
Technical specifications
Colour gray
Outer diameter 79.2 mm
Flame-retardant Yes
Bending radius 200 mm
min. operating temperature -40 °C
Material PA
max. operating temperature 140 °C
Inner diameter 66.5 mm
Nominal width 70 mm
Logistics
Customs tariff number 39173300
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
