707409 | HELUKABEL
PUR encoder cable TOPGEBER 512 PUR 6 x 2 x 2 x 0.25 mm² + 2 x 0.5 mm², AWG 20, shielded, orange, 707409
Unit Price (€ / mtr.)
6.9139 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Drag chain cable, 707409, HELUKABEL
The 707409 is a special PUR drag chain feedback cable transmit the control pulses for positioning and operating characteristics of servomotors. This cable is used as connecting cables for tachos, brakes and pulse generators in applications subjected to heavy mechanical stresses in industrial equipment, machine tools, control and automation equipment.
Technical specifications
| Core insulation material | polypropylene | |
| Colour | orange | |
| Number of cores | 6 | |
| Outer diameter | 7.2 mm | |
| AWG cross-section | AWG 20 | |
| Test voltage | 2 kV | |
| Halogen free | Yes | |
| Cable cross-section | 2 x 2 x 0.25 mm² + 2 x 0.5 mm² | |
| Version | encoder cable | |
| Material | PUR | |
| Cable material | copper, tin-plated | |
| Shielding | shielded | |
| Temperature range (unmoved) | -40 °C to 80 °C | |
| Temperature range (active) | -30 °C to 80 °C | |
| Conductor category | CL.6 = finest stranded |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
