53201 | HELUKABEL
PO high current stranded cable N2XCH 2 x 2.5 mm², unshielded, black, 53201
Unit Price (€ / mtr.)
5.7358 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Power cable, 53201, HELUKABEL
The power cable with enhanced characteristics in case of fire is used in power stations. The concentric conductor can be used as a PE or PEN conductor or as screen. Suitable for fixed installation in dry, damp or wet environments, in, above, on and beneath plaster as well as in masonary walls and in concrete. This cable is suitable for outdoor applications and in underground by using in conduits or tubes.
Features
- Halogen-free, no liberation of corrosive or toxic gases
- Low smoke development
- Limited propagation of fire
Technical specifications
| Core insulation material | XLPE | |
| Colour | black | |
| Number of cores | 2 | |
| Protective conductor available | No | |
| Outer diameter | 13 mm | |
| Test voltage | 4 kV | |
| Halogen free | Yes | |
| Cable cross-section | 2.5 mm² | |
| Version | high current stranded cable | |
| Material | PO | |
| Cable material | copper, bright | |
| Shielding | unshielded | |
| Rated voltage U0 | 600 V | |
| Temperature range (unmoved) | -30 °C to 90 °C | |
| Temperature range (active) | -5 °C to 50 °C | |
| Rated voltage | 1 kV |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| RoHS conform | Yes |
