43053 | HELUKABEL
PVC installation line (N)YM(St)-J 7 G 1.5 mm², AWG 16, shielded, gray, 43053
Unit Price (€ / mtr.)
3.8080 € *
Standard delivery time from the manufacturer is: 6 Weeks
Installation cable, 43053, HELUKABEL
The 43053 is a PVC installation cable with static screen, designed for the effective limitation of electromagnetic interference fields. The design proves to be advantageous for installation in the computer sector, in hospitals, in industrial control rooms with interference-sensitive devices as well as in living areas of people that are extremely sensitive to radiation. Suitable for installation in dry, damp or wet environments; for installation above, on, in and under plaster as well as in masonry walls and in concrete, however not for direct embedding in vibration, compacted or tamped concrete. Also suitable for outdoor installation as long as the cable is protected against direct sunlight.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | PVC | |
| Cable material | copper, bright | |
| Version | installation line | |
| Conductor category | CL.1 = stranded | |
| Number of cores | 7 | |
| Shielding | shielded | |
| Core insulation material | PVC | |
| Test voltage | 2 kV | |
| Cable cross-section | 1.5 mm² | |
| Core colour sequence | black | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Temperature range (active) | -5 °C to 70 °C | |
| Rated voltage U0 | 300 V | |
| Protective conductor available | Yes | |
| Outer diameter | 13 mm | |
| Colour | gray | |
| Rated voltage | 500 V | |
| Halogen free | No | |
| AWG cross-section | AWG 16 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
