32203 | HELUKABEL
PVC high current stranded cable NYCY 2 x 2.5 mm², AWG 14, black, 32203
Unit Price (€ / mtr.)
2.5942 € *
Standard delivery time from the manufacturer is: 6 Weeks
High current stranded cable, 32203, HELUKABEL
The 32203 is a power cable for energy supply is used for industry and distribution boards, power stations, house connecting boxes and street lighting as well as control cable for the transmission of control impulses and test datas. Overall, where increased electrical and also mechanical protection are required. This cable is installed in open air, in underground, in water, in concrete, indoors and in cable ducts.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Material | PVC | |
| Cable material | copper, bright | |
| Version | high current stranded cable | |
| Conductor category | CL.1 = stranded | |
| Number of cores | 2 | |
| Core insulation material | PVC | |
| Test voltage | 4 kV | |
| Cable cross-section | 2.5 mm² | |
| Temperature range (unmoved) | -40 °C to 70 °C | |
| Temperature range (active) | -5 °C to 50 °C | |
| Rated voltage U0 | 600 V | |
| Outer diameter | 13.5 mm | |
| Colour | black | |
| Rated voltage | 1000 V | |
| Halogen free | No | |
| AWG cross-section | AWG 14 |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
| SVHC free | Yes |
