51283 | HELUKABEL

XLPO-switching strand, halogen free, HELUTHERM 145, 0.5 mm², brown, outer Ø 1.9 mm, 51283

Order No.: 93F6325
EAN: 4060892231032
MPN:
51283
Series: HELUTHERM 145
51283 HELUKABEL Insulated stranded wires
Image may differ
Unit Price (€ / mtr.)
0.6307 € *
Available: 200 mtr.
Available in 5 Days: 6,000 mtr.
Leadtime: 6 Weeks **
Total Price:
126.14 € *
*incl. VAT plus shipping costs
**Subject to prior sale
200 mtr.
0.6307 €

Stranded wire, 51283, HELUKABEL

The 51283 temperature-resistant stranded wire is suitable for the internal wiring of lighting fixtures, heaters, electrical machinery, switching systems and distributors in industrial equipment as well as plant and machinery construction. This product is also used for laying in tubes on and under plaster, in closed installation ducts, as well as for traffic systems and outdoor applications.

Features

  • Temperature-resistant single core
  • Enhanced characteristics during fire conditions
  • Cross-linked insulation material
Technical specifications
Core insulation material XLPO
Colour brown
Outer diameter 1.9 mm
Test voltage 3.5 kV
Halogen free Yes
Cable cross-section 0.5 mm²
Cable material copper, tin-plated
Rated voltage U0 300 V
Temperature range (unmoved) -55 °C to 145 °C
Temperature range (active) -35 °C to 120 °C
Conductor category CL.5 = fine stranded
Standard number VDE 0295
Rated voltage 500 V
Logistics
Customs tariff number 85444995
Compliance
Date of RoHS guidelines 3/31/15
SVHC free Yes
RoHS conform Yes
