46606 | HELUKABEL

Silicone-switching wire, halogen free, SiD, 1.5 mm², gray, outer Ø 2.5 mm, 46606

Order No.: 93F4171
EAN: 4099891180751
MPN:
46606
Series: SiD
46606 HELUKABEL Insulated stranded wires
Image may differ
Unit Price (€ / mtr.)
0.714 € *
Standard delivery time from the manufacturer is: 6 Weeks
Total Price:
71.40 € *
*incl. VAT plus shipping costs
Subject to prior sale
100 mtr.
0.714 €

Silicone single core, 46606, HELUKABEL

Special single core for use in high, resp. low temperature areas. It is used mainly in the steel producing industries, in aviation industries as well as in ship building, cement, glas and ceramic factories.

Features

  • Halogen-free
  • Core insulation of silicone
  • High flash points
  • Resistant to high molecular oils
Technical specifications
Filter Property Value
Core insulation material silicone
Temperature range (active) -5 °C to 90 °C
Test voltage 2 kV
Colour gray
Halogen free Yes
Outer diameter 2.5 mm
Conductor category CL.1 = stranded
Temperature range (unmoved) -60 °C to 180 °C
Rated voltage U0 300 V
Standard number VDE 0250
Rated voltage 500 V
Product type switching wire
Cable material copper, tin-plated
Cable cross-section 1.5 mm²
Logistics
Property Value
Customs tariff number 85444995
Compliance
Property Value
RoHS conform Yes
SVHC free Yes
Date of RoHS guidelines 3/31/15
