29396 | HELUKABEL
PVC-switching strand, 05V-K, 1.0 mm², dark blue/white, outer Ø 2.8 mm, 29396
Unit Price (€ / mtr.)
0.6545 € *
Available in 5 Days: 3,000 mtr. - if ordered today
Switching strand, 29396, HELUKABEL
This PVC single core cable is determined for the installation to the inside of apparatus as well as for the protective laying to the lightings, in dry rooms, in production facilities, switch and distributor boards, in tubes, under and surface mounting of plasters.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Halogen free | No | |
| Colour | dark blue/white | |
| Test voltage | 2 kV | |
| Cable cross-section | 1.0 mm² | |
| Outer diameter | 2.8 mm | |
| Rated voltage U0 | 500 V | |
| Temperature range (active) | -5 °C to 70 °C | |
| Rated voltage | 300 V | |
| Temperature range (unmoved) | -30 °C to 80 °C | |
| Core insulation material | PVC | |
| Conductor category | CL.5 = fine stranded | |
| Cable material | copper, bright |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
