28799 | HELUKABEL
PVC-switching wire, H07V-U, 2.5 mm², AWG 14, gray, outer Ø 3.9 mm, 28799
Unit Price (€ / mtr.)
0.7378 € *
Available in 5 Days: 1,900 mtr. - if ordered today
Total Price:
73.78 € *
Price list
Quantity
Price per unit*
100 mtr.
0.7378 €
500 mtr.
0.6783 €
1000 mtr.
0.6426 €
5000 mtr.
0.5831 €
*incl. VAT plus shipping costs
Subject to prior sale
PVC single core, 28799, HELUKABEL
The 28799 is a PVC single core for installation in electrical conduits, on or under plaster or similar enclosed systems. Suitable for protected and fixed installation in lighting systems or switching and control devices up to and including 1000 V AC voltage or up to 750 V DC voltage against earth. Not suitable for direct laying in cable ladders and cable trays, except as a potential equalization cable. The materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers.
Technical specifications
| Filter | Property | Value |
|---|---|---|
| Rated voltage | 750 V | |
| Bending radius unmoved | 15.6 mm | |
| Colour | gray | |
| Temperature range (unmoved) | -30 °C to 80 °C | |
| Conductor category | CL.1 = stranded | |
| Core insulation material | PVC | |
| Outer diameter | 3.9 mm | |
| Halogen free | No | |
| Test voltage | 2.5 kV | |
| Temperature range (active) | 5 °C to 70 °C | |
| AWG cross-section | AWG 14 | |
| Cable material | copper, bright | |
| Cable cross-section | 2.5 mm² | |
| Rated voltage U0 | 450 V |
Download
Logistics
| Property | Value |
|---|---|
| Customs tariff number | 85444995 |
Compliance
| Property | Value |
|---|---|
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
| RoHS conform | Yes |
