28773 | HELUKABEL
PVC-switching wire, H05V-U, 0.75 mm², red, outer Ø 2.5 mm, 28773
Unit Price (€ / mtr.)
0.2701 € *
Available: 200 mtr.
Available in 5 Days: 3,000 mtr. - if ordered today
Total Price:
27.01 € *
Price list
Quantity
Price per unit*
100 mtr.
0.2701 €
500 mtr.
0.2475 €
1000 mtr.
0.2332 €
5000 mtr.
0.2118 €
*incl. VAT plus shipping costs
Subject to prior sale
PVC single core, 28773, HELUKABEL
The 28773 is a PVC single core for installation in electrical conduits, on and under plaster, but only for signal and control circuits. Suitable for protected and fixed installation in appliances and luminaires. The materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers.
Technical specifications
| Colour | red | |
| Rated voltage U0 | 300 V | |
| Temperature range (unmoved) | -30 °C to 80 °C | |
| Outer diameter | 2.5 mm | |
| Test voltage | 2 kV | |
| Core insulation material | PVC | |
| Cable material | copper, bright | |
| Rated voltage | 500 V | |
| Bending radius unmoved | 9.2 mm | |
| Temperature range (active) | 5 °C to 70 °C | |
| Halogen free | No | |
| Conductor category | CL.1 = stranded | |
| Cable cross-section | 0.75 mm² |
Download
Logistics
| Customs tariff number | 85444995 |
Compliance
| RoHS conform | Yes |
| SVHC free | Yes |
| Date of RoHS guidelines | 3/31/15 |
